Our 15R Beam, high brightness, stable quality, with all kinds of functions including color wheel, rotation gobo wheel, focus, rotation prism, frost etc.

Voltage: AC110-240V,50/60HZ
Lamp: Philips 330W lamp
Power consumption: 600W
Lens: 3-lens HQ optical group (0°- 3.9°focus)
Pan: 540degree (16bit)
Tilt: 270degree (16bit)
Color Wheel: 14 colors + open, with rainbow effect
Gobo Wheel: 8 rotation gobos (with gobo shaking/gobo flow) + 4 sizes of beams
Prism: 8-facet Rotating Prism
Packing Size: 450*400*503mm
Gross Weight: 20kg
Operation Modes:  ● DMX mode: 16CH/20CH  ● Master/Slave mode  ● Auto

CH1	Color Wheel		CH9	Focus
CH2	Strobe		CH10	Pan
CH3	Dimmer		CH11	Pan Fine
CH4	Gobo Wheel		CH12	Tilt
CH5	Gobo Wheel Rotation		CH13	Tilt Fine
CH6	Prism Insertion		CH14	Pan/Tilt Movement
CH7	Prism Rotation		CH15	ID address (100 for 3s) Reset(255 for 3s)
CH8	Frost
CH17	Pan/Tilt Speed		CH16	Lamp
CH18	Color Wheel Speed
CH19	Focus Speed
CH20	Gobo Wheel Speed
